VivoLink
Vivolink VLSW141H-8K video switch HDMI
Vivolink VLSW141H-8K video switch HDMI
Regular price
£199.55 GBP
Regular price
Sale price
£199.55 GBP
Taxes included.
Quantity
Couldn't load pickup availability
The VLSW141H-8K is a high-performance 4x1 HDMI switch, designed to manage multiple HDMI sources with ease. It supports HDMI 40Gbps bandwidth, enabling resolutions up to 8K@60Hz with 4:2:0 chroma subsampling and HDR+, ensuring exceptional video quality. The device is HDCP 2.3 compliant, ensuring compatibility with the latest content protection standards.
Key features include smart EDID management for seamless integration with various display devices, support for Audio Return Channel (eARC), and audio de-embedding capabilities, allowing extraction of audio signals for separate processing. The switcher offers both automatic and manual switching modes, providing flexibility in source selection. Its ultra-slim design facilitates easy installation in diverse environments.
Key features include smart EDID management for seamless integration with various display devices, support for Audio Return Channel (eARC), and audio de-embedding capabilities, allowing extraction of audio signals for separate processing. The switcher offers both automatic and manual switching modes, providing flexibility in source selection. Its ultra-slim design facilitates easy installation in diverse environments.
| Ports & interfaces | |
|---|---|
| Video port type | HDMI |
| RS-232 ports | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 5 |
| Number of HDMI outputs | 1 |
| HDMI in | 4 |
| Audio (L/R) out | 1 |
| S/PDIF out port | No |
| 3.5 mm (1/8-inch) out | Yes |
| Features | |
| Audio output channels | 2.0 channels |
| HD type | 8K Ultra HD |
| Remote control type | IR + RS232 |
| Product colour | Black |
| Plug and Play | Yes |
| Maximum resolution | 7680 x 4320 pixels |
| Maximum refresh rate | 60 Hz |
| LED indicators | Yes |
| HDCP | Yes |
| Bandwidth | 40 Gbit/s |
| Maximum frame rate | 60 fps |
| Audio formats supported | PCM |
| HDCP version | 2.3 |
| Consumer Electronics Control (CEC) support | Yes |
| Extended display identification data (EDID) | Yes |
| High Dynamic Range (HDR) supported | Yes |
| Power | |
| AC input voltage | 100 - 240 V |
| Weight & dimensions | |
| Width | 239 mm |
| Height | 124 mm |
| Empty weight | 415 g |
| Depth | 134 mm |
| Weight | 415 g |
| Dimensions (WxDxH) | 188 x 105 x 21 mm |
| Package width | 239 mm |
| Package height | 124 mm |
| Package depth | 134 mm |
| Package weight | 560 g |
| Technical details | |
| Audio output channels | 2.0 channels |
| HD type | 8K Ultra HD |
| Remote control type | IR + RS232 |
| Operating temperature (T-T) | -5 - 55 °C |
| Width | 239 mm |
| Height | 124 mm |
| Empty weight | 415 g |
| Depth | 134 mm |
| Product colour | Black |
| Video port type | HDMI |
| Plug and Play | Yes |
| Maximum resolution | 7680 x 4320 pixels |
| Maximum refresh rate | 60 Hz |
| LED indicators | Yes |
| HDMI version | 2.1 |
| HDMI ports quantity | 5 |
| HDCP | Yes |
| Remote control included | Yes |
| Bandwidth | 40 Gbit/s |
| Maximum frame rate | 60 fps |
| Audio formats supported | PCM |
| Audio support | Yes |
| Packaging data | |
| Package width | 239 mm |
| Package height | 124 mm |
| Package depth | 134 mm |
| Package weight | 560 g |
| Packaging content | |
| Mounting brackets included | Yes |
| Packaging content | 1x 8K UHD 4x1 HDMI Switcher |
| Manual | Yes |
| Remote control included | Yes |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 55 °C |
