Vivolink VL120004 audio amplifier 2.0 channels Home Black

VL120004 is a digital amplifier (Class-D) with 2 line & 1 MIC inputs, which supports EQ control and MIC mixing. With 2x20W@4 Ohm as default output, it can be switched to 1x40W@8 Ohm by bridge connection.


Controlable via button, RS232 (optional IR via IR-VL120004).

Audio
Frequency range	20 - 20000 Hz
Audio output channels	2.0 channels
Amplifier class	D
Total Harmonic Distortion (THD)	1%
Signal-to-Noise Ratio (SNR)	80 dB
RMS power output per channel (4 Ohm)	20 W
RMS power output per channel (8 Ohm)	20 W
Bridge-mode power output per channel (8 Ohm)	40 W
Bridge-mode power output per channel (4 Ohm)	40 W
Ports & interfaces
Phono audio in (L,R)	Yes
Speakers connectivity type	3.5mm
Audio (L/R) in	1
Audio (L/R) out	1
Headphone outputs	1
Headphone connectivity	3.5 mm
DC-in jack	Yes
Technical details
Purpose	Home
Product colour	Black
Connectivity technology	Wired
Bass adjustment	Yes
Treble adjustment	Yes
Turntable connectivity	No
Remote control type	RS-232
Material	Metal
Bridge function	Yes
Display
Built-in display	No
Power
AC input voltage	110 -220 V
Weight & dimensions
Width	96 mm
Depth	87 mm
Height	38 mm
Weight	790 g
Indication
LED indicators	Yes
Packaging data
Package weight	894 g
Package width	267 mm
Package depth	204 mm
Package height	77 mm
Packaging content
Manual	Yes
