TERRA
TERRA MINISERVER G6 E-2434/32/2x960/C/WS2025E
TERRA MINISERVER G6 E-2434/32/2x960/C/WS2025E
Regular price
£5,075.30 GBP
Regular price
Sale price
£5,075.30 GBP
Taxes included.
Quantity
Couldn't load pickup availability
The TERRA MINISERVERS are perfect for small businesses or departments who appreciate central data administration and the shared use of information and resources.
Due to the compact construction the TERRA MINISERVER can be used in every office, in every environment.
Due to the compact construction the TERRA MINISERVER can be used in every office, in every environment.
| Processor | |
|---|---|
| Memory channels supported by processor | Dual |
| Processor cache | 12 MB |
| Processor frequency | 3.4 GHz |
| Processor boost frequency | 5 GHz |
| Number of processors installed | 1 |
| Processor model | E-2434 |
| Processor socket | LGA 1700 |
| Processor cores | 4 |
| Processor manufacturer | Intel |
| Motherboard chipset | Intel C262 |
| Maximum number of SMP processors | 1 |
| Processor family | Intel® Xeon® |
| Intel® Optane™ Memory Ready | No |
| Performance cores | 4 |
| Memory | |
| Internal memory | 32 GB |
| Memory slots | 2x DIMM |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| ECC | Yes |
| Storage | |
| Supported RAID controllers | Broadcom MegaRAID 9550-8i |
| Hot-swap | Yes |
| Total storage capacity | 1.92 TB |
| Supported HDD sizes | 2.5,3.5" |
| SSD interface | SATA III |
| SSD capacity | 960 GB |
| RAID support | Yes |
| RAID levels | 1 |
| Optical drive type | No |
| Number of SSDs installed | 2 |
| Internal drive bays | 4x 3.5"/2.5" (HotSwap-fähig) ¦ 2x 2.5" (für Festeinbau von SSDs) |
| Supported SSD sizes | 2.5", 3.5" |
| Graphics | |
| On-board graphics card model | Aspeed AST2600 |
| On-board graphics card family | Aspeed |
| Maximum graphics card memory | 64 MB |
| On-board graphics card | Yes |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Number of LAN controllers | 2 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Total number of SATA connectors | 6 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Optical drive | |
| Optical drive type | No |
| Design | |
| Optical drive type | No |
| Chassis type | Mini Tower |
| Cooling type | Active |
| Performance | |
| Compatible operating systems | Windows Server 2019¦ |
| Remote administration | Ja |
| Trusted Platform Module (TPM) | Yes |
| Operating system installed | Windows Server 2025 Essentials |
| Software | |
| Operating system language | Multilingual |
| Compatible operating systems | Windows Server 2019¦ |
| Operating system installed | Windows Server 2025 Essentials |
| Processor special features | |
| Intel® Optane™ Memory Ready | No |
| Power | |
| Number of main power supplies | 1 |
| Number of redundant power supplies installed | 1 |
| Number of redundant power supplies supported | 1 |
| Redundant power supply (RPS) support | No |
| Power supply input frequency | 50/60 Hz |
| Power supply | 450 W |
| Power supply input voltage | 100 - 240 V |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 75% |
| Operating temperature (T-T) | 10 - 35 °C |
| Certificates | |
| Certification | CE, production according to ISO9001 in Germany |
| Management features | |
| Remote administration | Ja |
| Technical details | |
| Trusted Platform Module (TPM) | Yes |
| Supported HDD sizes | 2.5,3.5" |
| Memory type | 2x DDR5 PC4800, UB ECC |
| Ethernet interface type | Gigabit Ethernet |
| Chassis type | Mini Tower |
| Motherboard manufacturer | Asus P13R-I |
| Compliance certificates | CE |
| Weight & dimensions | |
| Width | 200 mm |
| Height | 270 mm |
| Depth | 340 mm |
| Other features | |
| Memory type | 2x DDR5 PC4800, UB ECC |
| Motherboard manufacturer | Asus P13R-I |
