Neomounts FPMA-HAC100 Medical monitor arm ceiling 10-24" - h 0-170 cm - gas spring

The Neomounts ceiling mount, model FPMA-HAC100 is a tilt- and swivel ceiling mount for medical flat screens up to 24". This mount is a great choice for space saving placement or when wall mounting and floor placement is not an option.

Neomounts versatile tilt (55°) and swivel (370°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The support is easily height adjustable from 0 to 170 centimetres using a gas spring. Depth adjustable from 0 to 170 centimetres. An innovative cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.

Neomounts FPMA-HAC100 has two pivot points and is suitable for screens up to 24" (61 cm). The weight capacity of this product is 6 kg each screen. The ceiling mount is suitable for screens that meetVESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.

All installation material is included with the product.

Mounting
Maximum weight capacity (per display)	6 kg
Minimum screen size	25.4 cm (10")
Panel mounting interface	100 x 100,75 x 75 mm
Number of displays supported	1
Mounting type	Ceiling
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Distance to the wall (max)	170 cm
Maximum distance to ceiling	170 cm
Maximum weight capacity	6 kg
Maximum screen size	61 cm (24")
Ergonomics
Depth adjustment range	0 - 1890 mm
Height adjustment	Yes
Height adjustment range	0 - 1700 mm
Swivel angle range	0 - 370°
Swivel angle	370°
Tilt angle range	0 - 55°
Number of pivot points	3
Height adjustment type	Gas spring
Rotating	Yes
Tilt adjustment	Yes
Swivelling	Yes
Design
Product colour	White
Housing material	Aluminium
Technical details
Number of pivot points	3
Mounting type	Ceiling
Distance to the wall (max)	170 cm
Maximum distance to ceiling	170 cm
Product colour	White
Weight & dimensions
Depth	1890 mm
Height	1700 mm
Weight	13.6 kg
Package width	1250 mm
Package depth	390 mm
Package height	390 mm
Package weight	13.9 kg
Package net weight	13.9 kg
Packaging data
Package width	1250 mm
Package depth	390 mm
Package height	390 mm
Package weight	13.9 kg
Package net weight	13.9 kg
Logistics data
Master (outer) case width	1250 mm
Master (outer) case length	390 mm
Master (outer) case height	390 mm
Master (outer) case gross weight	18.2 kg
Products per master (outer) case	1 pc(s)
Country of origin	Taiwan
Products per pallet (EU)	4 pc(s)
Master (outer) case net weight	13.9 kg
Harmonized System (HS) code	7616991099
Other features
Mounting type	Ceiling
Country of origin	Taiwan
