Lanview LVN-1UMOUNT-24PORT-1G network switch Unmanaged Gigabit Ethernet (10/100/1000)

The Lanview LVN-1UMOUNT-24PORT-1G
is a high-performance, full gigabit intelligent Ethernet switch designed to meet the demands of modern networking environments.
Featuring 24 Gigabit RJ45 ports, this switch offers an impressive bandwidth of 48 Gbps, ensuring smooth and efficient data transmission.
It supports port isolation and boasts a transmission distance of up to 250 meters, making it ideal for a variety of applications.
With Quality of Service (QoS) for data prioritization and loop alarm capabilities, this switch guarantees reliable and optimized network performance.
It operates effectively in a wide temperature range of -10°C to 50°C and is designed for 1U rack-mounted installation.

Management features
Switch type	Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Network
Networking standards	IEEE 802.3
Full duplex	Yes
Flow control support	Yes
Auto MDI/MDI-X	Yes
Half duplex	Yes
Data transmission
MAC address table	8000 entries
Switching capacity	48 Gbit/s
Store-and-forward	Yes
Packet forwarding	Yes
Forwarding rate	35.71 Mpps
Design
On/off switch	No
LED indicators	Link
Housing material	Metal
Number of fans	0 fan(s)
Power
Surge protection voltage	6 kV
Input current	2 A
DC input voltage	12 V
Surge protection	Yes
Other features
Material	Metal
Warranty period	3 year(s)
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	500 mm
Depth	290 mm
Height	85 mm
Weight	2.2 kg
Packaging content
Rack mount kit	Yes
Manual	Yes
Packaging data
Package width	500 mm
Package depth	290 mm
Package height	85 mm
Package weight	2.7 kg
Rack mount kit	Yes
Manual	Yes
Technical details
Housing material	Metal
Warranty period	3 year(s)
Indication
LED indicators	Link
