Epson EB-685Wi (without mount)

HD-ready pen-interactive projector
This projector offers superb interactivity thanks to its dual pen capability. With a brightness of 3,500 lumens and HD-ready WXGA resolution, the EB-685Wi's ultra-short-throw design allows you to present large images from a very short distance with minimised shadows and glare. A 14,000:1 contrast ratio and HDMI input mean that students benefit from sharp, clear images.

High brightness and image quality
Epson’s 3LCD technology ensures high-quality images with equally high White and Colour Light Output for vivid colours and bright images, even in daylight, and three times brighter colours than competitive projectors{s1. With a scalable display size of up to 100 inches, two types of content can be displayed using the split-screen without compromising on quality.

Dual pen
Epson's interactive pens are now even more responsive and easy to use when annotating directly on screen. With the new dual pens, teacher and student or two students can work simultaneously using different attributes.

Highly reliable
Project for longer with improved reliability and a longer lamp life of up to 10,000 hours in eco mode.

Interact and enhance learning
Multi-PC projection software allows teachers and students to share content simultaneously. The moderator function allows teachers to remain in control, choosing what content to display. Combine two projectors to create one large interactive display. Split-screen capability allows teachers to display two separate types of content simultaneously, such as a lesson plan from a PC and a still image or video clip from a document camera.

Optional wireless capability
Wirelessly display content easily from a range of smart devices and Google Chromebooks using our iProjection App{s2.

Projector
Number of colours	1.07 billion colours
Projector native resolution	WXGA (1280x800)
Projection distance (wide)	0 - 0.4 m
Projection distance (tele)	0 - 0.6 m
Native aspect ratio	16:10
Screen size compatibility	1524 - 2540 mm (60 - 100")
Contrast ratio (dynamic)	14000:1
Zoom ratio	1.35:1
Zoom capability	Yes
Vertical scan range	100 - 120 Hz
Projector brightness (economic mode)	2900 ANSI lumens
Keystone correction, vertical	±3°
Keystone correction, horizontal	±3°
Projection technology	3LCD
Projector brightness	3500 ANSI lumens
Lamps
Lamp power	250 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Light source
Lamp power	250 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Lens system
Zoom ratio	1.35:1
Zoom capability	Yes
Focus	Manual
Focal length range	3.7 mm
Throw ratio	0.28 - 0.37:1
F-number (relative aperture)	1.6
Scanning frequency
Vertical scan range	100 - 120 Hz
Video
Video processing	10 bit
Video colour modes	Blackboard, Cinema, Dynamic, Presentation, sRGB, Whiteboard
Colour modes (2D)	Cinema, Dynamic
Audio
Built-in speaker(s)	Yes
RMS rated power	16 W
Sound emission
Noise level	35 dB
Noise level (economic mode)	30 dB
Technical details
Colour modes (2D)	Cinema, Dynamic
Product colour	Grey, White
Security features	Kensington lock, Password lock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
Option type	Air filter ELPAF38, Connection and control box, Document camera, External Speaker, Pen tip(Felt), Pen tip(Teflon), USB extension cable, Wall mount, Wireless LAN unit
Control panel	0.59 inch with D9
Box contents	2 x Pen tip(Teflon), 4 x Pen tip(Felt), Corner markers for auto screen adjustment, Driver and Utilities (CD), Installation/safety manual, Interactive pens, Main unit, Pen tray, Power cable, Projector feet, Quick Start Guide, Remote control incl. batteries, Safety wire set, Template Sheet, USB cable
Lamp power	250 W
Products per pallet	16 pc(s)
Quantity per pack	1 pc(s)
Products per pallet layer (UK)	4 pc(s)
Products per pallet layer	2 pc(s)
Products per pallet (UK)	32 pc(s)
USB display function	3 in 1: Image / Mouse / Sound
Other features	AV Mute Slide, Auto Calibration, Auto brightness adjustment, Automatic input selection, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Dynamic lamp control, Easy OSD pre-setting, Home Screen, Interactive, Long lamp life, MHL audio/video interface, Microphone input, PC Interactive, PC free annotation, Split-Screen-Function
Performance
Password protection	Yes
Vertical scan range	100 - 120 Hz
Noise level	35 dB
Noise level (economic mode)	30 dB
Features
Interactive	Yes
Password protection	Yes
Noise level	35 dB
Noise level (economic mode)	30 dB
Country of origin	Philippines
Compatible operating systems	Linux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04 LTS, Windows 10, Windows 8, Windows 8.1
Multimedia
Built-in speaker(s)	Yes
RMS rated power	16 W
Design
Cable lock slot type	Kensington
Product colour	Grey, White
Cable lock slot	Yes
Placement	Wall
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Packaging data
Package width	490 mm
Package depth	545 mm
Package height	260 mm
Package weight	9.54 kg
Security
Cable lock slot type	Kensington
Cable lock slot	Yes
Software
Bundled software	Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projector Management
Operational conditions
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	5 - 35 °C
Weight & dimensions
Package width	490 mm
Package depth	545 mm
Package height	260 mm
Weight	5.9 kg
Width	367 mm
Depth	400 mm
Height	149 mm
Package weight	9.54 kg
Packaging content
Bundled software	Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projector Management
Logistics data
Products per pallet	16 pc(s)
Quantity per pack	1 pc(s)
Products per pallet layer (UK)	4 pc(s)
Products per pallet layer	2 pc(s)
Products per pallet (UK)	32 pc(s)
Other features
Security features	Kensington lock, Password lock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
Interface	USB 2.0-A, USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11b/g/n (optional), VGA in (2x), VGA out, HDMI in (3x), Composite in, RGB in (2x), RGB out, MHL, Jack plug out, Jack plug in (3x), Microphone input, Sync. in, Sync. out
F-number (relative aperture)	1.6
Option type	Air filter ELPAF38, Connection and control box, Document camera, External Speaker, Pen tip(Felt), Pen tip(Teflon), USB extension cable, Wall mount, Wireless LAN unit
Control panel	0.59 inch with D9
Box contents	2 x Pen tip(Teflon), 4 x Pen tip(Felt), Corner markers for auto screen adjustment, Driver and Utilities (CD), Installation/safety manual, Interactive pens, Main unit, Pen tray, Power cable, Projector feet, Quick Start Guide, Remote control incl. batteries, Safety wire set, Template Sheet, USB cable
